Lizhi Yang

Reinforcement learning (RL), while powerful and expressive, can often prioritize performance at the expense of safety. Yet safety violations can lead to catastrophic outcomes in real-world deployments. Control Barrier Functions (CBFs) offer a principled method to enforce dynamic safety – traditionally deployed online via safety filters. While the result is safe behavior, the fact that the RL policy does not have knowledge of the CBF can lead to conservative behaviors. This paper proposes CBF-RL, a framework for generating safe behaviors with RL by enforcing CBFs in training. CBF-RL has two key attributes: (1) minimally modifying a nominal RL policy to encode safety constraints via a CBF term, (2) and safety filtering of the policy rollouts in training. Theoretically, we prove that continuous-time safety filters can be deployed via closed-form expressions on discrete-time roll-outs. Practically, we demonstrate that CBF-RL internalizes the safety constraints in the learned policy – both enforcing safer actions and biasing towards safer rewards – enabling safe deployment without the need for an online safety filter. We validate our framework through ablation studies on navigation tasks and on the Unitree G1 humanoid robot, where CBF-RL enables safer exploration, faster convergence, and robust performance under uncertainty, enabling the humanoid robot to avoid obstacles and climb stairs safely in real-world settings without a runtime safety filter.

Robot learning has produced remarkably effective “black-box” controllers for complex tasks such as dynamic locomotion on humanoids. Yet ensuring dynamic safety, i.e., constraint satisfaction, remains challenging for such policies. Reinforcement learning (RL) embeds constraints heuristically through reward engineering, and adding or modifying constraints requires retraining. Model-based approaches, like control barrier functions (CBFs), enable runtime constraint specification with formal guarantees but require accurate dynamics models. This paper presents SHIELD, a layered safety framework that bridges this gap by: (1) training a generative, stochastic dynamics residual model using real-world data from hardware rollouts of the nominal controller, capturing system behavior and uncertainties; and (2) adding a safety layer on top of the nominal (learned locomotion) controller that leverages this model via a stochastic discrete-time CBF formulation enforcing safety constraints in probability. The result is a minimally-invasive safety layer that can be added to the existing autonomy stack to give probabilistic guarantees of safety that balance risk and performance. In hardware experiments on an Unitree G1 humanoid, SHIELD enables safe navigation (obstacle avoidance) through varied indoor and outdoor environments using a nominal (unknown) RL controller and onboard perception.

Push recovery during locomotion will facilitate the deployment of humanoid robots in human-centered environments. In this paper, we present a unified framework for walking control and push recovery for humanoid robots, leveraging the arms for push recovery while dynamically walking. The key innovation is to use the environment, such as walls, to facilitate push recovery by combining Single Rigid Body model predictive control (SRB-MPC) with Hybrid Linear Inverted Pendulum (HLIP) dynamics to enable robust locomotion, push detection, and recovery by utilizing the robot’s arms to brace against such walls and dynamically adjusting the desired contact forces and stepping patterns. Extensive simulation results on a humanoid robot demonstrate improved perturbation rejection and tracking performance compared to HLIP alone, with the robot able to recover from pushes up to 100N for 0.2s while walking at commanded speeds up to 0.5m/s. Robustness is further validated in scenarios with angled walls and multi-directional pushes.

In this paper, we propose a multi-domain control parameter learning framework that combines Bayesian Optimization (BO) and Hybrid Zero Dynamics (HZD) for locomotion control of bipedal robots. We leverage BO to learn the control parameters used in the HZD-based controller. The learning process is firstly deployed in simulation to optimize different control parameters for a large repertoire of gaits. Next, to tackle the discrepancy between the simulation and the real world, the learning process is applied on the physical robot to learn for corrections to the control parameters learned in simulation while also respecting a safety constraint for gait stability. This method empowers an efficient sim-to-real transition with a small number of samples in the real world, and does not require a valid controller to initialize the training in simulation. Our proposed learning framework is experimentally deployed and validated on a bipedal robot Cassie to perform versatile locomotion skills with improved performance on smoothness of walking gaits and reduction of steady-state tracking errors.
